Cummins ISME345-30 Engine Overhaul Parts List
$0.00
In stock
SKU
Cummins ISME345-30 Engine Overhaul Parts List
Cummins ISME345-30 Engine Overhaul Parts List
| Cummins Part Name | Cummins Part Number | Quantity |
| Main Bearing | 3016770 | 7 |
| Main Bearing | 3016780 | 7 |
| Thrust Bearing | 4926017 | 2 |
| Thrust Bearing | 4926018 | 2 |
| Cylinder Liner Kit | 3803703 | 6 |
| Cylinder Liner | 3080760 | 1 |
| Cylinder Head | 2864024 | 1 |
| Cylinder Kit | 4024940 | 6 |
| Cylinder Liner | 3080760 | 1 |
| Crankshaft | 3073707 | 1 |
| Crankshaft Gear | 3084445 | 1 |
| Camshaft Gear | 3401439 | 1 |
| Camshaft | 4022816 | 1 |
| Camshaft Thrust Support | 3896335 | 1 |
| Connecting Rod | 3899450 | 6 |
| Connecting Rod | 3896970 | 1 |
| Connecting Rod Cap Screw | 3027108 | 2 |
| Connecting Rod Bearing | 3016760 | 12 |
| Connecting Rod Bearing | 3016761 | 12 |
| Connecting Rod Bearing | 3016762 | 12 |
| Connecting Rod Bearing | 3016763 | 12 |
| Connecting Rod Bearing | 3016764 | 12 |
| Bushing | 3896894 | 1 |
| Plain Washer | 69324 | 4 |
| Plain Washer | 3041247 | 1 |
| Plain Washer | 3895517 | 2 |
| Cylinder Tla Head | 2864028 | 1 |
| Cylinder Head Gasket | 4022500 | 1 |
| Air Compressor | 3104324 | 1 |
| Air Compressor Gasket | 4952625 | 1 |
| Thermostat | 4973373 | 1 |
| Thermostat Seal | 3335548 | 1 |
| Thermostat | 3335549 | 1 |
| Engine Tla Piston | 4022533 | 1 |
| Piston Pin | 4083244 | 1 |
| Piston Skirt Kit | 3803954 | 1 |
| Piston Top | 4022532 | 1 |
| Piston Skirt | 4070653 | 1 |
| Piston Pin | 4083244 | 1 |
| Retaining Ring | 3016652 | 2 |
| Piston Ring Set | 3803977 | 6 |
| Compression Piston Ring | 3893752 | 1 |
| Compression Piston Ring | 3899413 | 1 |
| Compression Piston Ring | 3899413 | 1 |
| Compression Piston Ring | 3893752 | 1 |
| O Ring Seal | 3033247 | 1 |
| O Ring Seal | 3033248 | 1 |
| Flywheel | 3252549 | 1 |
| Flywheel | 3252548 | 1 |
| Flywheel Ring Gear | 4851 | 1 |
| Lub Oil Pump Cover | 4003958 | 1 |
| Turbocharger | 4046026 | 1 |
| Starting Motor | 4985441 | 1 |
| Starting Motor | ST2S35 | |
| Starting Motor | 2871257 | 1 |
| Plain Woodruff Key | 3009953 | 1 |
| Oil Piston Ring | 3102367 | 1 |
| Oil Piston Ring Ring | 3102367 | 1 |
| Rectangular Ring Seal | 3047188 | |
| Retainer Plug of Lube Oil Pump | 3895718 | 1 |
| Mounting Spacer of Lube Oil Pump | 3895439 | 2 |
| Lubricating Oil Pump | 4003950 | 1 |
| Gear&Shaft of Lube Oil Pump | 4003961 | 1 |
| Lubricating Oil Pump Body | 4060579 | 1 |
| Plan Washer of Lube Oil Pump | 203518 | 1 |
| Pipe Plug of Cylinder Head | 3008465 | 16 |
| Expansion Plug of Cylinder Head | 3895479 | 2 |
| Sealing Washer of Cylinder Head | 3328328 | 7 |
| Compression Spring | 3010146 | 1 |
| Pressure Regulator Plunger | 3068979 | 1 |
| Viscosity Sensor | 3069728 | 1 |
| Alternator Pulley | 3046204 | 1 |
| V Ribbed Belt | 3028521 | 1 |
| Lock Nut | 70897 | 1 |
| Rectangular Ring Seal | 3047188 | 1 |
| Expansion Plug | 3007632 | 2 |
| Expansion Plug | 206741 | 8 |
| Expansion Plug | 3007635 | 6 |
| O Ring Seal | 3035026 | 6 |
| Injector | 4061851 | 6 |
| Injector Sleeve | 3417717 | 6 |
| Valve Insert | 3090704 | 24 |
| Valve Stem Guide | 4923471 | 24 |
| Valve Spring | 3895860 | 24 |
| Intake Valve of Cylinder Head | 4926069 | 12 |
| Valve Collet of Cylinder Head | 3275354 | 24 |
| Exhaust Valve | 3417779 | 12 |
| Valve Collet of Cylinder Head | 3275354 | 24 |
| Valve Spring Retainer | 3104151 | 24 |
| Valve Spring Guide | 3070072 | |
| Valve Stem Seal | 4003966 | 24 |
| Valve Stem Guide | 3417558 | a/r |
| Valve Insert of Cylinder Head | 3418044 | a/r |
| Valve Insert of Cylinder Head | 3418045 | a/r |
| Valve Insert of Cylinder Head | 3418046 | a/r |
| Water Tla Pump | 4972853 | 1 |
| Accessory Drive Pulley | 3883324 | 1 |
| Hexagon Head Cap Screw | 3018671 | 1 |
| Hexagon Head Cap Screw | 4022822 | 1 |
| Hex Flange Head Cap Screw | 4923187 | 29 |
| Hex Flange Head Cap Screw | 4022907 | 3 |
| Hex Flange Head Cap Screw | 3328637 | 5 |
| Hex Flange Head Cap Screw | 3328379 | 2 |
| Hex Flange Head Cap Screw | 3895438 | 2 |
| Hex Flange Head Cap Screw | 3895440 | 1 |
| Hex Flange Head Cap Screw | 4071043 | 8 |
| Captive Washer Cap Screw | 3012481 | 4 |
| Socket Head Cap Screw | 3023525 | 4 |
| Captive Washer Cap Screw | 3822067 | 2 |
| Seal R&I Tool | 3163565 | 1 |
| Ring Dowel | 3027106 | 2 |
| Spline Coupling Sleeve | 199358 | 1 |
